PARTNER

Be it for intra-city goods transportation, or for making collections or deliveries across rural areas, Partner is up for almost any job, on any terrain. With an understanding of the nuances of Indian roads,the transportations needs of the people and newly introduced emission standards, Partner is built to be a reliable vehicle with potential only surpassed by its functionality with new i-Gen BS6 Technology. Ashok Leyland‘s ‘Partner’ series is available in both 4 tyre and 6 Tyre with a modern cabin, impressive built quality, fuel-efficient engine and with best in class service intervals with warranty of 3 years / 300 000 km,the vehicle delivers best-in-class user experience, coupled with exceptional efficiency.

A modern freight carrier

Partner offers performance and efficiency on par with global standards. With a modern Euro cab, spacious car-like interiors, and a gross vehicle weight (GVW) of 6250 kg, 7200 kg, 7490 kg, Partner addresses various applications like parcel goods, durables, perishables and FMCG products, among others. The tilt-able cabin, low loading platform height and runner mounted load body enables service accessibility, customization and a wide choice of load body options. The turning radius and heavy-duty axles in Partner are augmented for handling tough conditions.

Powerful engine, superior mileage

Partner is powered by the ZD30 Turbo intercooled Bosch 2.2 Common Rail diesel engine, which guarantees 10% more power and mileage alongwith superior fuel-efficiency and improved turnaround time. The engine is combined with a 5-speed fully-synchromesh gearbox with overdrive function, to deliver a flat torque over a wide rpm range – best for city driving. The gear shifts are smoother, and the linear power delivery of the engine makes for lesser shifts.

Enhanced driver comfort and safety

The next-generation Partner not just offers superior mileage and performance, but also enhanced driver safety and comfort. The ‘Euro’ cabin is modern and comfortable, with air-conditioning (HVAC) options. Comfortable and safe interior ergonomics include dual-tone dashboard, moulded roof and door trims, tilt-able power steering, adjustable driver seat, windshield defogger, fog lamp, a lockable glove compartment, and 3-point seat belt. Partner features a braking system, along with Vacuum assisting and Load Conscious Regulating Valve (LCRV) for greater safety. The parabolic front suspension and semi-elliptical rear suspension, along with double acting shock absorbers on both the axles, makes the ride comfortable for the driver, irrespective of the payload or terrains.

Performance

  • Superior Load Carrying Capacity
  • Rated Payload upto 4885 kg
  • 4 Tyre and 6 Tyre Options
  • Load Body Options of Partner 4 Tyre – 3160 mm (10ft) and 4230mm (14ft)
  • Load Body Options of Partner 6 Tyre – 3415 mm (11ft) and 4230mm (14ft)
  • 10% More mileage
  • 10% More Fuel efficiency *

Safety

  • 3 Point Type ELR Seat Belt
  • Vacuum assisted Brakes with LCRV

Comfort

  • Modern Euro Cabin
  • Narrow cabin width(1.9 m)
  • Safe and Ergonomic Interiors
  • Optional AC with Heater Unit (HVAC)
  • Tiltable Power Steering

Heavy Duty

  • Heavy Duty Aggregates
  • Bigger clutch
  • Heavy Duty Axle
  • Front Parabolic Suspension Rear Semi Elliptical Suspension
Variant 3160mm (10ft) 4230mm (14ft)
WEIGHT
Gross Vehicle Weight 6250 kg 7200 kg
Rated Payload (FSD) 3760 kg 4565 kg
LOAD BODY DIMENSIONS
Load Body Length (mm) 3160 4230
Load Body Width (mm) (HSD) 1960 2060
Side Deck Height (mm) FSD : 460 – HSD : 1840
POWERTRAIN
Engine Type ZD30 Diesel Engine with DDTi (Double Overhead Camshaft, Common Rail, Direct Injection, Turbo Intercooled)
Displacement / Cubic Capacity 2953 cc
Maximum Power Output kW@rpm 104.3 kW@ 2750 rpm
Maximum Torque (Nm @ rpm) 360 Nm @ 1350-2750 rpm
Clutch Diaphragm Push Type,Single Dry Plate,Hydraulic actuated
Transmission Fully Syncronised 5 Speed gearbox Manual-Kinetic
Fuel Tank Capacity (in litres) 90 L
SUSPENSION & TYRES
Front Suspension Parabolic,overslung suspension with Double Acting Shock Absorbers
No of Leaf Springs (Front) Front : 3
Rear Suspension Semi-elliptic(main),overslung suspension with Double Acting Shock Absorbers
No of Leaf Springs (Rear) 6 main + 2 Helper
No. of Tyres Front 2, Rear 2, Spare 1
Tyre Size 8.25 x 16-16 PR
Loading Platform Height (mm) 1050 1035
Turning Circle Radius (TCR) (m) 6.2 7.5
Min. Ground Clearance (mm) 238
OVERALL DIMENSIONS
Wheel Base (mm) 2685 3335
Overall Length (mm) 4920 5990
Overall Height (mm) FSD : 2250HSD : 2850 FSD : 2250HSD : 2810
ELECTRICALS
Battery 1 x 75 AH
Alternator 70 A
STEERING
Steering System Power
BRAKES
Service Brake Vacuum Assist Hydraulic Brake
Exhaust Brakes No yes
Parking Brake Transmission mounted, Cable operated
PERFORMANCE
Grade ability 25%
Variant 3415mm (11ft) 4230mm (14ft) 5275mm (17ft)
WEIGHT
Gross Vehicle Weight 7490 kg 7490 kg 7490 kg
Rated Payload (FSD) 4885 kg 4775 kg 4579 kg
LOAD BODY DIMENSIONS
Load Body Length (mm) 3415 4230 5275
Load Body Width (mm) (HSD) 2060 2209
Side Deck Height (mm) FSD : 461 – HSD : 1840 HSD : 1122
POWERTRAIN
Engine Type ZD30 Diesel Engine with DDTi (Double Overhead Camshaft, Common Rail, Direct Injection, Turbo Intercooled)
Displacement / Cubic Capacity 2953 cc
Maximum Power Output kW@rpm 104.3 kW@ 2750 rpm
Maximum Torque (Nm @ rpm) 360 Nm @ 1350-2750 rpm
Clutch 310 mm Diameter, Diaphragm Push Type,Single Dry Plate,Hydraulic actuated
Transmission Fully Syncronised 5 Speed gearbox Manual-Kinetic
Fuel Tank Capacity (in litres) 90 L
SUSPENSION & TYRES
Front Suspension Parabolic,overslung suspension with Double Acting Shock Absorbers
No of Leaf Springs (Front) Front : 3 Front : 3 Front : 3
Rear Suspension Semi-elliptic(main),overslung suspension with Double Acting Shock Absorbers
No of Leaf Springs (Rear) 6 main + 4 Helper 6 main + 4 Helper 6 main + 4 Helper
No. of Tyres Front 2, Rear 2, Spare 1
Tyre Size 7.50 x 16,16 PR
Loading Platform Height (mm) 1042 1035 1085
Turning Circle Radius (TCR) (m) 5.7 6.72 7.8
Min. Ground Clearance (mm) 221 221
OVERALL DIMENSIONS
Wheel Base (mm) 2820 3320 3955
Overall Length (mm) 5170 5990 HSD : 7085
Overall Height (mm) FSD: 2240 HSD: 2832 HSD : 2870
ELECTRICALS
Battery 1 x 75 AH
Alternator 70 A (LS), 90 A (LX)
STEERING
Steering System Power
BRAKES
Service Brake Vacuum Assist Hydraulic Brake Pneumatic brakes
Exhaust Brakes / Air Brakes Exhaust Brakes Exhaust Brakes Air Brakes
Parking Brake Transmission mounted, Cable operated Parking brake integrated with rear brakes
PERFORMANCE
Grade ability 25% 25%
